7-Segment Display - LED (Red)
A single-digit 7-segment LED display in red with a common anode configuration. Features two decimal point positions, with the right-side decimal point wired ...
Get notified when back in stock
A single-digit 7-segment LED display in red with a common anode configuration. Features two decimal point positions, with the right-side decimal point wired and functional.
Key Features
- Single Digit 7-Segment – Common anode configuration
- Colour – Red
- Decimal Point – Right-side decimal point wired
- Digit Height – 0.6" (15.2mm)
- Overall Height – 1" (25.4mm)
Also Available
Resources
Jargon buster
Plain-language definitions for the technical terms used above.
- LED
- A light-emitting diode (LED) is a small electronic component that emits light when current flows through it in the correct direction. Because it only conducts one way, its polarity matters, and a through-hole LED must be soldered the correct way around to light up.
