RS485 to Ethernet Serial Server – 8-Channel, Rail-Mount, Isolated, PoE Optional
100 units will be available shortly.
Prepare for seamless industrial communication with our robust 8-Channel RS485 to RJ45 Ethernet Serial Server. This rail-mount isolated serial module is engineered to cater to the most demanding industrial environments, providing bi-directional transparent transmission and a multitude of connectivity options for data acquisition and IoT applications.
Product Highlights:
- Eight Independent RS485 Channels: Each channel operates without interference, allowing for smooth data exchange on multiple lines.
- Rail-mount Design: Built for the industrial sector, this device comes with a compact, easy-to-install, rail-mount metal case, making it perfect for both new installations and system upgrades.
- Versatile Functionality: Integrates as a serial server, Modbus gateway, MQTT gateway, and enables RS485 to JSON conversions, among other protocols.
- Dual Ethernet Connectivity: Equipped with two Ethernet ports (with optional PoE support), providing flexibility for network switching and hassle-free scalability.
- Isolation Protection: Ensures safety and reliability with power and signal isolation, shielding your data communications from electrical interference.
- Wide Power Supply Range: Operates on a DC 7V to 36V screw terminal input, with an optional Power over Ethernet (PoE) for tidier installations and reduced cabling concerns.
Specifications:
- Product Type: Industrial Serial Server
- Basic Function: Bi-directional transparent data communication between RS485 and Ethernet.
- Interfaces: 8 × RS485 ports, 2 × RJ45 Ethernet ports (PoE optional).
- Power Supply: Screw terminal (DC 7V ~ 36V) or optional PoE port.
- Communication Protocols: Ethernet, IP, TCP, UDP, HTTP, ARP, ICMP, DHCP, DNS, and more.
- Software Compatibility: Supports various web browsers and management functions libraries for ease of configuration.
- Working Environment: Designed to resist harsh conditions, with an operating temperature range of -40℃ ~ 85℃ and 5% ~ 95% relative humidity.
- Dimensions: 93 × 103.5 × 29.7 mm
Key Features:
- Flexible Installation: Choose between wall-mount and rail-mount options for a tailored setup to fit your infrastructure needs.
- Modbus Gateway: Ideal for integrating with Modbus networks and enhancing connectivity in industrial systems.
- Multi Communication Modes: Offers TCP server, TCP client, UDP multicast, and UDP modes to adapt to various network scenarios.
- MQTT/JSON Conversion: Facilitates integration with cloud services and IoT platforms, enhancing your data acquisition and monitoring capabilities.
- NTP Support: Retrieves accurate network time information for timed operations and data logging.
Whether you're setting up an intelligent monitoring system or enhancing your existing network, our 8-Channel RS485 to RJ45 Ethernet Serial Server brings robust performance, reliability, and versatility to your industrial operations. Upgrade your connectivity with this high-performance, adaptable solution and elevate your data management to the next level.
