Basic 16x2 Character LCD - White on Black 5V
$52.20
|
In stock
This is a basic 16 character by 2 line display with a snazzy black background with white characters. Utilizes the extremely common HD44780 parallel interface...
Get notified when back in stock
Estimated Delivery
Arrives
Disclaimer
Secure checkout
This is a basic 16 character by 2 line display with a snazzy black background with white characters. Utilizes the extremely common HD44780 parallel interface chipset (datasheet). Interface code is freely available. You will need ~11 general I/O pins to interface to this LCD screen. Includes white LED backlight.
