60-pin 0.5mm FFC / FPC Extender
Discontinued
A simple breakout board that connects two 60-pin 0.5mm pitch FFC (Flexible Flat Cable) or FPC (Flexible Printed Circuit) cables end-to-end, extending the total cable length. Uses two flip-lock ZIF connectors for secure, tool-free cable insertion.
Key Features
- End-to-End Extension – Join two FFC/FPC cables to increase reach
- Flip-Lock ZIF Connectors – Gently pry the ears to insert cables, push back to lock
- 0.5mm Pitch – Matches common display and camera ribbon cables
Specifications
- Pins – 60
- Pitch – 0.5mm
- Cable Type – FFC / FPC
Ideal For
- Extending display ribbon cables
- Reaching between enclosures or mounting points
- Prototyping with FFC/FPC connections
Package Contents
- 1× 60-pin 0.5mm FFC/FPC extender board
Note: Pin 1 of one connector connects to pin 60 of the other. Use type A-A cables (contacts on the same side of both ends).
