Raspberry Pi 2-Channel Isolated CAN Expansion HAT
We have ✅ 1 available of the WS-17912 in our Sydney warehouse. An extra 100 units will be available shortly.
2-Channel Isolated CAN Expansion HAT for Raspberry Pi - Dual Chips Solution
Unleash the full potential of your Raspberry Pi with our robust and efficient 2-Channel Isolated CAN Expansion HAT, empowered by the MCP2515 and SN65HVD230 dual-chip solution. A must-have for embedded systems engineers and hobbyists alike, this HAT is designed to provide isolated and stable CAN (Controller Area Network) bus communication, enabling your Raspberry Pi to connect with industrial, automotive, and other CAN-equipped devices.
Product Features:
- Dual Chips for Dual CAN Channels: Equipped with MCP2515 CAN controllers and SN65HVD230 CAN transceivers, this HAT offers two independent CAN communication channels, leading to more versatile and complex applications.
- Electrical Isolation: The onboard power isolation provides a stable isolated voltage that ensures safe and reliable communication across the CAN network without the need for an external power supply for the isolated terminal.
- Signal and Power Integrity: The integration of a digital isolator and a TVS diode secures your CAN network by providing enhanced signal stability, better anti-interference capabilities, and protection against ESD and transient voltage spikes.
Easy Configuration and Compatibility: - Jumper-Based Voltage and Resistance Selection: Flexible onboard jumper settings allow you to select the operating voltage (3.3V or 5V) and enable or disable the built-in 120Ω terminal resistor to match your system requirements. - Standard Raspberry Pi 40PIN GPIO Header: This HAT is custom-designed to fit seamlessly with any Raspberry Pi board with the standard GPIO header, offering a high degree of compatibility with the Raspberry Pi series.
Technical Specifications: - CAN Controller: MCP2515 - CAN Transceiver: SN65HVD230 - Logic Level Voltage: 3.3V or 5V (selectable via jumper) - Control Bus: SPI interface for easy connection to controllers like STM32 or Arduino - Dimensions: 65 × 56.5 mm - Operating Power: 5V supplied via the Raspberry Pi
Additional Benefits: - Bundled Resources: The product comes with a comprehensive manual and example codes in both C and Python to kickstart your project. Access detailed documentation and resources on our WIKI page at www.waveshare.com/wiki/2-CHCANHAT. - Mounting Essentials: Along with the 2-Channel CAN HAT, you get a Raspberry Pi screws pack and a 2×20PIN female header for secure and easy mounting.
In the Box: - 2-Channel CAN HAT x1 - Raspberry Pi screws pack x1 - 2×20PIN female header x1
Whether you are working on industrial control systems, IoT devices, or automotive applications, this 2-Channel Isolated CAN Expansion HAT is the reliable solution you need for seamless and secure CAN communication with your Raspberry Pi.
