Macchina OBD-II 3-Way Breakout
2 units will be available shortly.
Product Overview
Meet the OBD2 Breakout Board, your new best mate for streamlining OBD2 device development. This nifty board is equipped with junction blocks that let you adjust how signals are routed between connectors. Simply install a jumper wire between rows for "through" connections or hop over to other pins to rearrange signals as you see fit. With the ability to function in several "modes," you can tweak the signal paths to suit your project's needs.
Features & Specs
- Input Connector: 1 OBD2 connector with MALE pins
- Output Connectors: 2 connectors with FEMALE pins
- 12V Power Source: Use an external 12V power adapter for desktop OBD2 development. Alternatively, when using an OBD2 extension cable, power is derived from the vehicle
- Power Jumpers: Manage power to each output with the installation of jumpers
- Junction Blocks: Flexible routing of OBD2 signals to connectors. All signals are fully accessible
- CAN Termination Resistors: Includes 2 sets
- Power Indicator: Green LED lights up when power is ON
Documentation
The Macchina OBD-II 3-Way Breakout appears in the following collections:
SKU SF-BOB-25069
by SparkFun
