ESP32-C6 WiFi 6 Development Board - 160MHz, USB & UART Support
100 units will be available shortly.
Unlock the Future of Wireless Innovation with the ESP32-C6 WiFi 6 Development Board
Product Overview: Dive into the cutting-edge world of IoT development with the ESP32-C6 WiFi 6 Development Board. This compact yet powerful microcontroller is your key to designing and prototyping state-of-the-art smart devices. Designed to cater to a variety of applications ranging from smart homes to industrial automation, the ESP32-C6 development board offers reliable performance and a rich set of features.
Features:
- Powerful Processing: At its core lies the ESP32-C6-WROOM-1-NX Series Module with a 32-bit RISC-V single-core processor, roaring at a speed of up to 160MHz. Choose between models with 8MB or 16MB of built-in Flash memory for all your development needs.
- Next-Gen Connectivity: Embrace the capabilities of WiFi 6, Bluetooth 5, and IEEE 802.15.4 (Zigbee 3.0 and Thread), ensuring your projects are equipped with superior wireless performance and ready for a multitude of environments.
- Effortless Interface: Two onboard chips, CH343 and CH334, make development seamless with USB and UART connections through a USB-C port.
- Rich Expansion Options: Rich in peripheral interfaces including SPI, UART, I2C, I2S, LED PWM, SDIO, and others, the board is compatible with the pinout of the ESP32-C6-DevKitC-1, for hassle-free expanding and prototyping.
- Robust Design Credential: The castellated module design enables direct soldering to carrier boards, further simplifying the product development cycle.
- Comprehensive Support: Leverage a plethora of online tutorials and examples for the ESP-IDF development environment, ensuring a streamlined path from concept to product.
Development Kits:
- ESP32-C6-DEV-KIT-N8: Perfect for starting your project, this kit features an 8MB Flash and includes two sets of 40PIN male pin headers.
- ESP32-C6-DEV-KIT-N8-M: Geared for convenience, this version comes with pre-soldered headers and an 8MB Flash.
- ESP32-C6-DEV-KIT-N16: Need more memory? Opt for this kit with 16MB Flash, bundled with two sets of 40PIN male pin headers.
- ESP32-C6-DEV-KIT-N16-M: This variant offers 16MB Flash and pre-soldered headers, saving you time and effort in setup.
Dimensions & Weight:
- Compact Size: The ESP32-C6 development board boasts a small footprint, making it ideal for space-constrained applications.
- Lightweight: With a weight of just 0.013 kg, it adds minimal heft to your final product.
Get Started Today!
Each development board comes equipped with everything you need to jump right into the world of IoT development. Utilize our comprehensive Wiki for detailed guidance and support.
Order your ESP32-C6 WiFi 6 Development Board now and be at the forefront of IoT innovation!
