ESP32-S3 AMOLED Touch Watch Dev Board – Dual-Core, 410x502, Dual Mics
We have ✅ 10 available of the WS-31957 in our Sydney warehouse. An extra 100 units will be available shortly.
Unleash Your Creativity with the ESP32-S3 2.06inch AMOLED Touch Watch Development Board
Take your wearable tech designs to the next level with the powerful and versatile ESP32-S3 2.06inch AMOLED Touch Watch Development Board. This sleek, cutting-edge development tool is crafted for tinkerers, developers, and tech enthusiasts who crave high performance, vibrant displays, and intuitive interfaces all wrapped up in a smartwatch-sized package.
Product Specifications:
- Processor: Xtensa 32-bit LX7 Dual-core processor running at up to 240MHz
- Display: 2.06-inch AMOLED with a dazzling 410×502 resolution
- Touch Interface: Capacitive touch panel with FT3168 touch controller
- Memory: 512KB of SRAM and 384KB ROM, plus 8MB PSRAM and 32MB external Flash
- Connectivity: Wi-Fi (802.11 b/g/n) and Bluetooth 5 (LE) with an integrated antenna
- Microphones: Onboard dual digital microphone array for clear audio capture
- Sensors: QMI8658 6-axis IMU for motion tracking and gesture recognition
- Power Management: AXP2101 power management IC for efficient energy use
-
Additional Features:
- Custom-designed case for a smartwatch look and feel
- Type-C connector for modern connectivity
- Onboard speaker, TF card slot, programmable PWR and BOOT buttons
- Various interfaces including I2C, UART, and USB reserved pads
Display and Touch:
Embrace the future of screen technology with an AMOLED display that delivers high contrast, a wide viewing angle, vibrant colors, and low power consumption. Experience responsive touch interactions with the FT3168 touch chip and revel in the visual clarity provided by the CO5300 display driver.
Wireless Capabilities:
Stay connected with built-in Wi-Fi and BLE 5 support, enabling seamless integration with a vast range of devices and services. Develop applications that require constant connectivity and leverage the onboard antenna for reliable wireless communication.
Sensory Excellence:
With the onboard 6-axis IMU and RTC chip, this development board becomes an extension of the user, responding to motion and gesture while keeping accurate time even during power downtime, thanks to a backup lithium battery option.
Sound and Interaction:
Make your projects heard with the onboard dual digital microphones. Whether it's voice commands or ambient sound detection, this board provides the clarity needed for effective communication and audio processing.
Programming and Development:
The ESP32-S3-Touch-AMOLED-2.06 is ready to support your development journey with comprehensive SDKs, resources, and tutorials for both ESP-IDF and Arduino environments. Whether you're a seasoned programmer or a curious novice, you'll find the tools you need to bring your wearable applications to life.
Power Options:
Choose the standard version for direct power, or opt for the variant with an MX1.25 lithium battery that neatly fits inside the watch casing, offering portable power for on-the-go development.
Showcase Your Style:
Complete with detachable watch straps, this development board is perfect for tech enthusiasts who not only demand functionality but also value aesthetic appeal and personalization.
What's Included:
- ESP32-S3-Touch-AMOLED-2.06 Main Board x1
- Stylish Watch Straps x1
- with MX1.25 Lithium Battery x1
Bring your wearable ideas to life and innovate on the go with the ESP32-S3 2.06inch AMOLED Touch Watch Development Board. It's more than a development tool—it's a style statement, an innovation platform, and a stepping stone to the future of integrated wearable technology.
For further information, schematics, and technical guides, please visit the official Waveshare wiki page at www.waveshare.com/wiki/ESP32-S3-Touch-AMOLED-2.06.
Embark on your next project with confidence, knowing you have the ESP32-S3 at your wrist!
Weight: 0.066 kg
Quick Overview: - ESP32-S3-Touch-AMOLED-2.06 Development Board x1 - Watch Straps x1 - (Optional) MX1.25 Lithium battery x1
(Choice of standard or battery-included variant available)
The ESP32-S3 AMOLED Touch Watch Dev Board – Dual-Core, 410x502, Dual Mics appears in the following collections:
SKU WS-31957
by Waveshare
