Octopus PM2.5 module
100 units available with a short lead time.
The Octopus PM2.5 module from ElecFreaks is a laser-based particulate matter sensor built around the ZH03B dust sensor. It measures PM2.5 concentration in the air with high consistency and real-time response, capable of detecting particles as small as 0.3 µm in diameter.
Part of the Octopus electronic brick series, it features both a 3-pin GVS interface (PWM output) and a 4-pin serial output, making it compatible with micro:bit, Arduino, and other 3.3 V or 5 V microcontrollers.
Key Features
- ZH03B Laser Dust Sensor – High-accuracy PM2.5 concentration measurement
- 0.3 µm Minimum Particle Size – Detects fine particulate matter
- Dual Output – 3-pin GVS (3.3 V PWM) and 4-pin serial (3.3 V UART)
- 3.3 V / 5 V Compatible – Works with micro:bit, Arduino, and similar boards
- Real-Time Response – Continuous air quality monitoring
Specifications
- Sensor – ZH03B laser dust sensor
- Measurement – PM2.5 concentration (µg/m³)
- Minimum Particle Size – 0.3 µm
- Interfaces – 3-pin GVS (PWM) and 4-pin serial (UART)
- Operating Voltage – 3.3–5 V
Ideal For
- Air quality monitoring stations
- Environmental science projects with micro:bit
- Indoor air quality sensing
- Arduino and microcontroller pollution monitoring
Resources
The Octopus PM2.5 module appears in the following collections:
SKU EF-EF04090
