SparkFun Triple Axis Accelerometer Breakout - MMA8452Q (Qwiic) [SF-SEN-14587]

SparkFun Triple Axis Accelerometer Breakout - MMA8452Q (Qwiic)

SparkFun Triple Axis Accelerometer Breakout - MMA8452Q (Qwiic) [SF-SEN-14587]

Price: $18.70
Fastest delivery: Monday, 13th December
Order before 2pm Wednesday, 1st December
Available with a lead time
(76 units can dispatch between Dec 10 to Dec 15)
Need more than 0 units?
πŸ”’ Secure transaction
Ships from: Little Bird (SYD) β†’ You
Ships from: Supplier β†’ Little Bird (SYD) β†’ You

Product Image Gallery

Photo of SparkFun Triple Axis Accelerometer Breakout - MMA8452Q (Qwiic) Photo of SparkFun Triple Axis Accelerometer Breakout - MMA8452Q (Qwiic) Photo of SparkFun Triple Axis Accelerometer Breakout - MMA8452Q (Qwiic) Photo of SparkFun Triple Axis Accelerometer Breakout - MMA8452Q (Qwiic) Photo of SparkFun Triple Axis Accelerometer Breakout - MMA8452Q (Qwiic)

Description

This breakout board makes it easy to use the tiny MMA8452Q accelerometer communicate over I2C in your project. The MMA8452Q is a smart low-power, three-axis, capacitive MEMS accelerometer with 12 bits of resolution. This accelerometer is packed with embedded functions with flexible user programmable options, configurable to two interrupt pins. Embedded interrupt functions allow for overall power savings relieving the host processor from continuously polling data. This version of the SparkFun Triple Axis Accelerometer Breakout includes pre-soldered Qwiic connectors for rapid prototyping and better ease of use. With the connectors already soldered on, you can jump right into using this little board without any assembly!

The MMA8452Q has user selectable full scales of Β±2g/Β±4g/Β±8g with high pass filtered data as well as non filtered data available real-time. The device can be configured to generate inertial wake-up interrupt signals from any combination of the configurable embedded functions allowing the MMA8452Q to monitor events and remain in a low power mode during periods of inactivity.

This board also breaks out the ground, power, I2C and two external interrupt outputs into 0.1" spaced pins.


The SparkFun Qwiic Connect System is an ecosystem of I2C sensors, actuators, shields and cables that make prototyping faster and less prone to error. All Qwiic-enabled boards use a common 1mm pitch, 4-pin JST connector. This reduces the amount of required PCB space, and polarized connections mean you can’t hook it up wrong.


GET STARTED WITH THE QWIIC MMA8452Q BREAKOUT HOOKUP GUIDE
