OBD-II connector
A bare OBD-II connector for building custom automotive diagnostic tools and vehicle data interfaces. OBD-II (On-Board Diagnostics II) is a standardised diagn...
A bare OBD-II connector for building custom automotive diagnostic tools and vehicle data interfaces. OBD-II (On-Board Diagnostics II) is a standardised diagnostic port found on most cars, providing access to engine control unit (ECU) data for troubleshooting, monitoring, and data logging.
This connector is compatible with most vehicles that use the OBD-II standard. The 16-pin connector is typically located under the dashboard on the driver's side. Wire it to your microcontroller or SBC to build a custom diagnostic reader or vehicle data logger.
Key Features
- Standard OBD-II Connector – 16-pin, compatible with most OBD-II equipped vehicles
- Bare Connector – Unassembled, for custom wiring and integration
- Universal Compatibility – Fits the standard OBD-II port found in most cars
Specifications
- Standard – OBD-II
- Pins – 16
- Type – Bare connector (no cable or breakout board)
Ideal For
- DIY automotive diagnostic readers
- Vehicle data logging and telemetry projects
- CAN bus and ECU communication experiments
- Custom OBD-II breakout boards
Package Contents
- 1× OBD-II connector
