Netduino 2

$60.37

Part Number:  SF-DEV-11663
Brand:  SparkFun Australia

Are you a fan of the Netduino? Are you a .NET developer looking for a capable 32-bit development board? Well we’ve got good news! Secret Labs have updated their classic Netduino to create: Netduino 2! Netduino 2 is still the same Arduino shield compatible board you know and love, except faster with more code space. Powered by an STmicro Cortex-M3 microcontroller running at 120MHz, the...
We can dispatch today: - units (delivered by -)
We can dispatch in - days: - units (delivered by -)

Retired Product

This product has been retired from our catalog and is no longer for sale. This page is made available for those looking for datasheets and the simply curious.

Contact us on (02) 9457 8865 or help@littlebirdelectronics.com and we'll help you find the up-to-date version.

Are you a fan of the Netduino? Are you a .NET developer looking for a capable 32-bit development board? Well we’ve got good news! Secret Labs have updated their classic Netduino to create: Netduino 2!

Netduino 2 is still the same Arduino shield compatible board you know and love, except faster with more code space. Powered by an STmicro Cortex-M3 microcontroller running at 120MHz, the Netduino 2 packs 192KB of code space and 60KB of RAM. With built-in hardware peripherals like UART, PWM, I2C, 12-bit ADC and DAC, the Netduino 2 is ready to interface with whatever you throw at it. That includes Arduino R3-style shields, since Netduino 2 adds two GPIO over its predecessor.

Features:

  • STMicro 32-bit microcontroller
  • Speed: 120MHz, Cortex-M3
  • Code Storage: 192 KB
  • RAM: 60 KB
  • Power LED and User LED
  • Button Acts as reset by default but can be used as input device
  • Vin: 7.5 - 9.0 VDC or USB powered
  • Vout: 5 VDC and 3.3 VDC regulated
  • Max Current: 25 mA per pin
  • GPIO are 3.3V but 5V tolerant

Includes:

  • Netduino 2
  • 4 x Sticky Feet
  • 3ft Micro Usb Cable
