Digital Servo Motor
Dimensions: 1.57" x 0.79" x 1.44" (40 x 20 x 44mm)
Weight: 38g
Operating Speed (4.8V no load) : 0.14sec / 60 degrees
Operating Speed (6.0V no load) : 0.11sec / 60 degrees
Stall Torque (4.8V): (8 kg/cm) (110oz/in.)
Stall Torque (6.0V): (11kg/cm) (156oz/in.)
Temperature Range: -30 to +60 Degree C
Dead Band Width: 4ms
Operation Voltage: 3.5 - 8.4Volts
Weight: 38g
Operating Speed (4.8V no load) : 0.14sec / 60 degrees
Operating Speed (6.0V no load) : 0.11sec / 60 degrees
Stall Torque (4.8V): (8 kg/cm) (110oz/in.)
Stall Torque (6.0V): (11kg/cm) (156oz/in.)
Temperature Range: -30 to +60 Degree C
Dead Band Width: 4ms
Operation Voltage: 3.5 - 8.4Volts
Features: Compliant with most standard receiver connector: Futaba, Hitec, Sanwa, GWS etc...
Great for truck, Boat, Racing Car, Helicopter and Airplane.
Power Supply: Through External Adapter.
Stable and Shock Proof.
Coreless Motor
Double Ball Bearing
Light Weight
Less Noise
Connector Wire Length 300mm
Great for truck, Boat, Racing Car, Helicopter and Airplane.
Power Supply: Through External Adapter.
Stable and Shock Proof.
Coreless Motor
Double Ball Bearing
Light Weight
Less Noise
Connector Wire Length 300mm
