1000uF 16VDC Low ESR Electrolytic Capacitor

A 1000µF 16V low-ESR electrolytic capacitor rated for 105°C operation. Low-ESR capacitors provide stable, low-impedance characteristics, making them well suited for power supply filtering, voltage ripple reduction, and input/output smoothing.

With a ripple current rating of 1400mA RMS and an extended load life of 2,000–4,000 hours at 105°C, this capacitor is designed for demanding applications where reliability matters.

Key Features

• Low ESR – Stable, low-impedance performance for cleaner power delivery
• 1400mA Ripple Current – High ripple handling at 105°C / 100kHz
• 105°C Rated – Extended temperature range for demanding environments
• Long Life – 2,000–4,000 hours load life at rated temperature
• Through-Hole Radial – Standard pitch leads for easy PCB mounting

Specifications

• Capacitance – 1000µF
• Voltage Rating – 16V DC
• Type – Electrolytic, low ESR, polarised
• Impedance – 0.046Ω max @ 20°C / 100kHz
• Ripple Current – 1400mA RMS @ 105°C / 100kHz
• Operating Temperature – Up to 105°C
• Diameter – 10mm
• Height – 20mm
• Package – Radial, through-hole

Ideal For

• Power supply filtering and smoothing
• Voltage ripple reduction
• DC-DC converter output filtering
• Audio amplifier power rails

Package Contents

• 1× 1000µF 16V low-ESR electrolytic capacitor
