2x3 Male SMD Header - 0.1in Pitch

This compact 2x3-pin male SMD header is a simple board-level connector for projects that need a standard 0.1 inch pitch interface. It provides six male pins in two rows, suitable for mating with compatible 2.54 mm pitch connectors.

The header is unshrouded and designed for surface-mount soldering, with a push-pull fastening style. It uses gold contact finish on the mating side and tin finish on the post side.

A datasheet is available for checking footprint, mechanical details and compatibility before you commit it to a PCB design.

Specifications:

• Contact Type: Male pin
• Pitch - Mating: 0.100" (2.54mm)
• Number of Positions: 6
• Number of Rows: 2
• Row Spacing - Mating: 0.100" (2.54mm)
• Shrouding: Unshrouded
• Mounting Type: Surface Mount
• Termination: Solder
• Fastening Type: Push-Pull
• Contact Length - Mating: 0.240" (6.10mm)
• Insulation Height: 0.090" (2.29mm)
• Contact Shape: Square
• Contact Finish - Mating: Gold
• Contact Finish Thickness - Mating: 15.0µin (0.38µm)
• Contact Finish - Post: Tin
• Contact Material: Copper Alloy
• Insulation Material: Liquid Crystal Polymer (LCP), Glass Filled
• Material Flammability Rating: UL94 V-0
• Insulation Color: Black
• Contact Finish Thickness - Post: 74.8µin (1.90µm)
• Mfg Part #: 0015910060

Useful for custom PCBs, programming connections and other compact 2.54 mm pitch interconnects.
