Right Angle Female Header - SMD, 0.1in, 3-Pin
· MPN: PRT-26992
This compact 3-pin female header is designed for surface-mount applications where you need a right-angle connection on a PCB.It uses 0.1" spacing between row...
Get notified when back in stock
This compact 3-pin female header is designed for surface-mount applications where you need a right-angle connection on a PCB.
It uses 0.1" spacing between rows and between pins, making it suitable for common maker and prototyping layouts that use standard 2.54 mm pitch headers.
Sold as individual units, so you can order exactly the quantity needed for a repair, prototype or small production run.
Specifications:
- Connector type: Female header
- Pin count: 3-pin
- Orientation: Right angle
- Mounting type: SMD
- Pin spacing: 0.1" spacing between rows and between pins
- Quantity: Sold as individual units
