DIP Switch - 8 Position
A standard DIP switch with 8 individual switch positions at 0.1″ (2.54mm) pin spacing. Fits directly into breadboards and standard PCB through-holes for easy...
Get notified when back in stock
A standard DIP switch with 8 individual switch positions at 0.1″ (2.54mm) pin spacing. Fits directly into breadboards and standard PCB through-holes for easy prototyping and configuration.
Specifications
- Positions – 8 individual switches
- Pin Spacing – 0.1″ (2.54mm)
- Mounting – Through-hole (breadboard compatible)
Ideal For
- Configuration and address setting on PCBs
- General-purpose control switches
- Breadboard prototyping
Package Contents
- 1× DIP Switch (8 Position)
