Bright Green 1206 SMD LED - IN-S126ATG
· MPN: COM-27914
This compact surface-mount indicator LED emits a bright green light and comes in the common 1206 package size, making it suitable for PCBs, prototypes and sm...
Get notified when back in stock
This compact surface-mount indicator LED emits a bright green light and comes in the common 1206 package size, making it suitable for PCBs, prototypes and small production runs.
It is the same green LED used on SparkFun RedBoard products and many other boards, so it is a handy choice when you want a familiar status, power or activity indicator.
A datasheet is available from the manufacturer for detailed footprint and electrical guidance.
Specifications:
- Color: Green
- Configuration: Standard
- Lens Color: Colorless
- Lens Transparency: Clear
- Millicandela Rating: 560mcd
- Lens Style: Rectangle with Flat Top
- Lens Size: 2.00mm x 1.50mm
- Voltage - Forward (Vf) (Typ): 3.2V
- Current - Test: 20mA
- Viewing Angle: 120°
- Mounting Type: Surface Mount
- Wavelength - Dominant: 520nm
- Wavelength - Peak: 526nm
- Dimensions: 3.20mm L x 1.50mm W
- Height: 1.10mm
- Mfg Part #: IN-S126ATG
