Qwiic OLED Display - 1.5in 128x128

Name: Qwiic OLED Display - 1.5in 128x128
Brand: SparkFun
SKU: SF-LCD-29530
Price: 57.19 AUD
Availability: InStock

· MPN: LCD-29530

Displays Displays & User Interface LCD & OLED Displays SparkFun Qwiic Ecosystem

$57.19 |

In stock at supplier

No reviews yet

This compact OLED board gives your project a crisp monochrome white-on-black interface in a 1.5-inch square form factor. With 128x128 pixels and a 1:1 aspect...

Add to Wishlist

Compare

Estimated Delivery

Arrives

Disclaimer

View Markdown

Secure checkout

This compact OLED board gives your project a crisp monochrome white-on-black interface in a 1.5-inch square form factor. With 128x128 pixels and a 1:1 aspect ratio, it suits custom graphics, menus, status screens and data plotting.

The display uses Chip-on-Glass (COG) OLED technology, so each pixel emits its own light without a bulky backlight. This helps keep the module thin and power-efficient while delivering strong contrast and deep blacks compared with traditional LCDs.

For fast prototyping, the board includes two Qwiic connectors for default I2C communication, so it can be connected with a Qwiic cable without soldering or breadboarding. If your application needs faster refresh rates, standard 0.1-inch pins are broken out for SPI communication.

SPI use requires cutting traces on the back of the board and using a microcontroller with 3.3V logic. Documentation provided by SparkFun includes the schematic, KiCad files, hookup guide, datasheets and GitHub repository.

Features:

Qwiic Connect System: Two Qwiic connectors capable of I2C communication for plug-in connection with a Qwiic cable.
SPI Capable: Standard 0.1" pins are broken out for SPI communication.
Chip-on-glass OLED design eliminates the need for a backlight.
Suitable for graphics, text and data plotting.

Specifications:

Display size/resolution: 1.5" square 128x128 pixel display
Display: WEO128128HWAP3N00000
Display colour: Monochrome White on Black
Display Area: 26.86mm x 28.86mm
Display Driver: CH1120
I2C Interface: I2C Interface (Default)
Addresses: Ox3C (Default) 0x3D
SPI Interface: SPI Interface (Alternate)
Logic level: 3.3V Logic Only
Header: 0.1"-spaced PTH Header
Power indicator: Red Power LED
Connectors: 2x Qwiic Connectors

A neat display option for Qwiic-based projects, compact instruments, handheld gadgets and embedded user interfaces.
