IN-PI554FCH 5050 Addressable RGB SMD LED - Cut Tape
· MPN: COM-26982
The IN-PI554FCH is a 5050-size surface-mount RGB LED with an integrated constant-current IC and RGB LED chip, suited to custom PCBs and compact lighting proj...
The IN-PI554FCH is a 5050-size surface-mount RGB LED with an integrated constant-current IC and RGB LED chip, suited to custom PCBs and compact lighting projects.
Each LED is supplied as an individual cut-tape unit. It is intended for SMD assembly, so good surface-mount soldering skills and suitable tools are recommended before adding it to your board.
A datasheet is available from the manufacturer for footprint, pinout and timing details.
Features:
- 4-pin design
Specifications:
- Red wavelength: 620-625nm
- Red light intensity: 500-1000mcd
- Red working current: 12mA
- Red working voltage: 1.8-2.2V
- Green wavelength: 520-525nm
- Green light intensity: 1000-1700mcd
- Green working current: 12mA
- Green working voltage: 2.8-3.2V
- Blue wavelength: 465-470nm
- Blue light intensity: 500-1000mcd
- Blue working current: 12mA
- Blue working voltage: 2.8-3.2V
Useful for makers and designers building addressable RGB lighting directly into their own surface-mount electronics.
