DIN Rail RJ-45 To Terminal Block Adapter - Right Angle Jack
A practical DIN rail-mountable adapter that breaks out all 8 wires from an RJ-45 (Ethernet) cable into individual screw terminal blocks. It's ideal for simpl...
A practical DIN rail-mountable adapter that breaks out all 8 wires from an RJ-45 (Ethernet) cable into individual screw terminal blocks. It's ideal for simplifying wiring in enclosures and panel builds — connect a single RJ-45 cable and distribute power or data to sensors, displays, microcontrollers, and other devices without any soldering.
This variant features a right-angle RJ-45 jack, keeping the cable profile low and parallel to the DIN rail. No soldering required — just loosen the terminal screws, insert stranded or solid-core wire, and tighten.
Key Features
- DIN Rail Mount – Clips directly to standard DIN rail for clean panel installation
- 8-Way Breakout – All 8 RJ-45 conductors broken out to individual terminal blocks
- Right-Angle Jack – Cable exits parallel to the rail, saving panel depth
- No Soldering – Screw terminal blocks accept stranded or solid-core wire
- Versatile Use – Power and signal distribution to sensors, microcontrollers, displays, and more
Ideal For
- Panel builders using DIN rail enclosures
- Makers running multi-conductor cable using RJ-45 connectors
- Distributing power and low-speed data in control cabinet builds
