Alchitry Br Wide V2 Breakout Board
· MPN: DEV-27877
The Br V2 is a breakout board for Alchitry headers, giving you access to all the signal pins through solder-friendly 0.1" holes. It is designed to make wirin...
Get notified when back in stock
The Br V2 is a breakout board for Alchitry headers, giving you access to all the signal pins through solder-friendly 0.1" holes. It is designed to make wiring, prototyping and adding your own circuitry easier when working with an Alchitry board.
This is the wide version, recommended for most uses with the newer boards because their stack height is only 4mm. The extra width helps reduce worries about solder joints hanging below the board.
Take care around the holes above the USB port, as there is very little clearance underneath. Documentation is available from the supplier, including a schematic plus Standard and Wide STEP 3D models.
Specifications:
- Signal breakout: All signal pins on the Alchitry headers
- Hole spacing: 0.1"
- Stack height: 4mm
- Clearance note: The holes above the USB port have very little clearance underneath.
