12.3" Capacitive Touch IPS LCD - 1920x720, HDMI, Toughened Glass

A 12.3-inch ultra-wide IPS touchscreen with a 1920×720 resolution, toughened glass panel, and optical bonding. The wide-format display is well suited for dashboards, instrument clusters, and bar-type information displays. At 600 cd/m², it is bright enough for well-lit environments.

The 10-point capacitive touch panel connects via USB and is plug-and-play with Raspberry Pi OS — no drivers required. Video input is via HDMI, compatible with Raspberry Pi, Jetson Nano/TX2/Xavier NX/Orin, and Windows/Linux PCs. An OSD menu allows brightness and contrast adjustments.

Key Features

• 1920×720 Ultra-Wide IPS – Wide-format display with 178° viewing angles
• 10-Point Capacitive Touch – Responsive multi-touch via USB
• Toughened Glass (6H) – Scratch and impact resistant with optical bonding
• 600 cd/m² Brightness – Excellent visibility in bright conditions
• HDMI Input – Plug-and-play with Raspberry Pi and other SBCs
• Audio Output – 3.5mm jack and 24-pin header

Specifications

• Screen Size – 12.3 inches
• Resolution – 1920×720
• Panel Type – IPS
• Touch – Capacitive, 10-point
• Glass Hardness – 6H (toughened), optically bonded
• Brightness – 600 cd/m²
• Viewing Angle – 178°
• Video Input – HDMI
• Touch Interface – USB
• Audio Output – 3.5mm jack + 24-pin header
• Power – 12V/3A (adapter included)
• Operating Temperature – −20°C to 70°C
• Weight – 1.223 kg

Compatibility

• Raspberry Pi (Raspberry Pi OS — plug-and-play)
• Jetson Nano / TX2 / Xavier NX / Orin
• Ubuntu, Kali, WIN10 IoT, RetroPie
• Windows and Linux PCs

Ideal For

• Dashboard and instrument cluster displays
• Kiosk and HMI touch interfaces
• Industrial and commercial signage
• Raspberry Pi and Jetson projects

Package Contents

• 1× 12.3-inch HDMI LCD
• 1× HDMI cable
• 1× USB-A to Micro-B cable (touch)
• HDMI and USB adapters
• 1× Button board (OSD controls)
• 1× 12V/3A power adapter
• Screws pack
