FT230X USB 2.0 to UART Bridge IC
· MPN: COM-29754
Add USB serial connectivity to a microcontroller design with this compact FT230X USB bridge IC. It converts USB 2.0 to a UART interface, making it a straight...
Get notified when back in stock
Add USB serial connectivity to a microcontroller design with this compact FT230X USB bridge IC. It converts USB 2.0 to a UART interface, making it a straightforward way to provide USB communication in embedded projects.
The device is engineered with an optimised pin count for space-constrained applications, helping reduce PCB footprint and simplify board layout when adding USB connectivity.
Documentation is available in the form of a datasheet for electrical details, pin information and design guidance.
Specifications:
- Protocol: USB
- Function: Bridge, USB to UART
- Interface: UART
- Standards: USB 2.0
- Voltage - Supply: 3.3V ~ 5V
- Current - Supply: 8mA
- Operating Temperature: -40°C ~ 85°C
- Mfg #: FT230XQ-R
Suited to custom PCBs and embedded designs that need a small USB-to-serial UART interface IC.
