SparkFun USB LiPoly Charger - Single Cell
The SparkFun USB LiPoly Charger is a single-cell Li-Ion/Li-Polymer battery charging board based on the MCP73831T. It charges 3.7V LiPo cells at a selectable ...
Get notified when back in stock
The SparkFun USB LiPoly Charger is a single-cell Li-Ion/Li-Polymer battery charging board based on the MCP73831T. It charges 3.7V LiPo cells at a selectable rate of 500 mA or 100 mA via a solder jumper, with power input from either USB or a barrel jack connector.
The board includes a SYS OUT JST connector that lets you power your project directly from the charger without disconnecting the battery — ideal for always-connected setups where charging and operation happen simultaneously.
Key Features
- MCP73831T Charge IC – Reliable single-cell LiPo/Li-Ion charging
- Selectable Charge Rate – 500 mA or 100 mA via solder jumper
- Dual Power Input – USB and barrel jack connector
- SYS OUT Connector – JST output for powering your project while charging
- BATT IN Connector – Pre-installed JST connector for battery
- Status LED – Indicates charging state, with footprint for external LED
Ideal For
- Charging single-cell 3.7V LiPo/Li-Ion batteries
- Battery-powered Arduino and IoT projects
- Wearable electronics
- Portable devices requiring charge-while-running
