SparkFun RGB LED Breakout - WS2812
Discontinued
A breakout board for a single WS2812 addressable RGB LED — the same LED used in NeoPixel strips and rings. The WS2812 integrates a WS2811 driver directly into the LED package, so each breakout needs only a single data line to control full 24-bit colour.
All pins are broken out to 2.54 mm (0.1″) headers for easy breadboarding. Multiple boards can be daisy-chained together via the data output pin to form addressable LED strings or displays.
Key Features
- WS2812 RGB LED – Integrated WS2811 driver, 24-bit colour (16.7 million colours)
- Chainable – Data output pin for daisy-chaining multiple breakouts
- Breadboard-Friendly – 2.54 mm (0.1″) header spacing
- Single Data Line – One-wire control from any microcontroller
Specifications
- LED: WS2812 (integrated WS2811 driver)
- Colour Depth: 24-bit (8-bit per channel)
- Supply Voltage: 5 V DC
- Interface: Single-wire serial data
- Header Pitch: 2.54 mm (0.1″)
Ideal For
- Prototyping addressable LED projects
- Building custom LED arrays and displays
- Learning single-wire LED control
Package Contents
- 1× WS2812 RGB LED Breakout Board
