Gravity LED Button for Arduino and micro:bit - Red
· MPN: DFR0785-R
This compact illuminated push-button module is designed for interactive electronics and quick prototyping. A transparent cap sits over an internal red LED, g...
Get notified when back in stock
This compact illuminated push-button module is designed for interactive electronics and quick prototyping. A transparent cap sits over an internal red LED, giving instant visual feedback when the button is pressed.
The module provides a simple digital output for microcontroller input detection: when pressed, it outputs High and the internal LED lights up; when released, it outputs Low and the LED turns off. The Gravity PH2.0 connector makes wiring straightforward with compatible Gravity boards, Arduino projects, micro:bit controllers and other suitable development platforms.
It is well suited to classroom experiments, DIY control panels, game inputs, robotics interfaces and human-machine interface prototypes. The pack includes one Gravity: LED Button - Red and one Digital Sensor Connector.
Features:
- Integrated LED lights up automatically when the button is pressed
- Digital signal output for simple microcontroller input detection
- Transparent button cap for clear visual indication
- Gravity PH2.0 connector for quick plug-and-play wiring
- Multiple LED colour options: red, yellow, green, blue, white
Specifications:
- Operating Voltage: +3.3-5V (3.3V is recommended)
- Output: digital
- Connector: PH2.0-3P
- Dimension: 27×26.5mm/1.06×1.04”
- Colors Available: red, yellow, green, blue, white
