Pi STEMMA QT Breakout for Raspberry Pi
· MPN: ADA6365
This compact breakout adds a 4-pin JST SH connector to a Raspberry Pi or compatible board, giving you a quick STEMMA QT/Qwiic connection for I2C sensors and ...
This compact breakout adds a 4-pin JST SH connector to a Raspberry Pi or compatible board, giving you a quick STEMMA QT/Qwiic connection for I2C sensors and devices. The 2x3 socket plugs onto the Pi’s I2C and power pins with no soldering required, so it is easy to fit and remove when you need it.
The board connects to SDA, SCL, 3V and Ground, and includes a 3.3V regulator to help power STEMMA QT and Qwiic devices without causing a brownout dip. A green power LED shows when it is powered correctly, and two 10K pull-up resistors are included for Pi-compatible boards that do not already provide them.
It can also be used with Linux single board computers or microcontrollers that have a 2x20 Pi-compatible pinout. For software, Adafruit’s Blinka Python interface library lets you use many CircuitPython libraries on SBC computers from Python.
Features:
- STEMMA QT/Qwiic connector: Adds a 4-pin JST SH connector for quick I2C device connection.
- No soldering required: 2x3 socket plugs directly onto the Raspberry Pi I2C bus pins.
- Pi-compatible pinout: Works with Raspberry Pi and compatible boards using a 2x20 Pi-compatible header.
- I2C connections: Breaks out SDA, SCL, 3V and Ground.
- 3.3V regulator: Helps power Qwiic or STEMMA QT devices without risking a brownout dip.
- Power indicator: Green LED shows the board is powered correctly.
- Pull-up resistors: Includes two 10K pull-up resistors for compatible boards that need them.
- Blinka support: Compatible with Adafruit Blinka for using CircuitPython libraries on SBC computers with Python.
Specifications:
- Product Dimensions: 15.2mm x 15.0mm x 5.5mm / 0.6" x 0.6" x 0.2"
- Product Weight: 1.1g / 0.0oz
Ideal for quickly adding I2C sensors, displays and other STEMMA QT or Qwiic devices to Raspberry Pi projects without header fiddling.
