0.85in IPS LCD Display 128×128 SPI, 65K Colour

Jargon buster

Plain-language definitions for the technical terms used above.

BL

BL usually stands for backlight, the light source that makes an LCD visible. Some modules let you control this pin to turn the backlight on, dim it, or save power in battery projects.

CLK

CLK is a clock line that times when bits are sent and read on a synchronous serial bus such as SPI. Any device using a clock line must have its CLK connected to the controller's clock output so the two stay in step while data is transferred.

Colour depth

Colour depth describes how many different colours a display can show. A 65K-colour display can show about 65,000 colours, which is useful for icons, graphs, and simple full-colour interfaces but is less detailed than modern phone or computer screens.

CS

CS stands for chip select, a control pin used by SPI devices to tell which connected device should listen. It matters when you connect more than one SPI module to the same microcontroller, because each device usually needs its own CS pin.

DC

DC means direct current, where electricity flows in one constant direction, as supplied by batteries, USB ports and many plug-pack power supplies. When a product specifies DC, it runs from a DC supply rather than mains AC, so you need to provide the correct voltage and polarity.

DIN

As a pin label, DIN stands for 'data in', the input through which a device receives serial data from a controller, as found on SPI displays, LED drivers and other serial modules. DIN can also refer to the German standards body of that name, as in a round multi-pin DIN connector or DIN-rail mounting.

GND

GND is the ground or reference connection (0 V) for a circuit. When connecting two devices together, their grounds must be joined so both agree on what counts as a low or high signal.

GPIO

General-purpose input/output pins are microcontroller pins you can set in software to read signals, switch devices on and off, or connect to peripherals. The number of GPIO pins matters because it limits how many buttons, LEDs, sensors, and other parts you can wire directly to the board.

IPS

IPS is a type of LCD panel that keeps colours and contrast more consistent when viewed from an angle. This matters for small displays that may be mounted in a dashboard, handheld project, or enclosure where the viewer is not always looking straight on.

LCD

LCD stands for liquid crystal display, a screen technology that uses a backlight and liquid crystals to show images or text. It matters because LCD modules usually need a display driver and enough controller pins or a bus interface to send image data.

microcontroller

A microcontroller is a small computer on a single chip that runs a stored program and controls connected inputs and outputs such as buttons, sensors, displays and communication interfaces. In a device built around one, it is the part that executes the code and coordinates the device's behaviour.

RST

RST (reset) is a control pin used to restart or reinitialise a device to a known state. Connecting an RST pin to a microcontroller lets the host reset the device, which can help with reliable start-up or recovery.

SPI

A fast serial communication bus often used for displays, memory cards, and sensors. It matters because SPI devices need specific pins for clock and data, plus a separate chip-select line for each device.

VCC

VCC is the positive power-supply connection on a chip or module. Connecting it to the correct supply voltage is needed for the part to power on and helps avoid damaging the electronics.
